For testing the surface tension
To determine the cleanliness of surfaces

For more information, please visit us at:

www.arcotest.info
Our offer is aimed exclusively at traders.
All prices are exclusive of of statutory VAT.

New

arcospray® 38

The arcospray 38 test ink is a testing liquid with a surface tension of 38 mN/m. I t has been designed to quickly detect whether the surface is grease-free, as values equal or greater than that mean freedom from grease. After its application, arcospray® 38 can be removed without residue using oil-free clean blower air (compressed air). Tested parts can be used further. arcospray 38 makes it possible to quickly and easily assess large and small surfaces, such as chain links, alike.

• Optimal for very small and large areas
• Easy to use
• Not toxic
• Not harmful to health
• Not harmful to the environment
• residue-free testing of surfaces
• Simply spray on the arcospray ink
• result visible within 2 seconds
• Test non-contact surfaces


38 mN/m • 38 dyne/cm
with accuracy: +/- 1,0 mN/m

Available:
100 ml spray bottle

See more

arcotest® ORGANIC Test Inks

arcotest® ORGANIC Test Inks are special testing liquids in ranges of defined surface tension – in green colour. They were developed to obtain non-toxic test inks that do not require labelling. The application and handling of arcotest® ORGANIC is based on DIN 53364 re. ISO 8296.
ORGANIC Test Inks are label-free according to the Ordinance on Hazardous Substances (EU) No. 1272/2008 (CLP).
The arcotest® ORGANIC Test Inks are available in bottles or in pens.

Recommendation:
If the surface is dirty, no test pens should be used, since there could be residual dirt on the test surface, which remains in the felt of the pens and falsifies subsequent values.
For metal surfaces, use test inks with
• Bottles with arcotest® cotton swabs or
• arcoweb

See more

ORGANIC in bottles

30 to 46 mN/m
with accuracy: +/- 0,5 mN/m

Available:
in bottles of 10, 100 or 250 ml
or in sets of 7 bottles of 10 ml

See more
Test Pens

Test Pens arcotest® ORGANIC

30 to 46 mN/m
with accuracy: +/- 1,0 mN/m

Available:
in sets of 4, 6, and 8
or as single pens, 5 ml

See more

arcotest® ORGANIC Jumbo

30 to 46 mN/m
with accuracy: +/- 1,0 mN/m

Available:
in sets of 4, 6, and 8
or as single pens, 17 ml

See more

arcoweb® tissues

38 mN/m
with accuracy: +/- 1,0 mN/m

Available:
in individual packaging

See more

arcotest® Test Pens PINK

The PINK Test Inks are special testing liquids in ranges of defined surface tension. They were developed to get “non toxic” Test Inks. These pink Test Inks aremeant to substitute the blue coloured inks as they were declared to be toxic according to DIN 53364 / ISO 8296.

The PINK Test Inks are available in bottles or in pens.
Non-toxic.

observation time:
from 22 to 26 mN/m : 2 sec.
from 28 to 44 mN/m : 4 sec.
from 45 to 60 mN/m : 2 sec.

See more

Test Inks PINK in bottles

22 to 60 mN/m
with accuracy: +/- 0,5 mN/m

Available:
in bottles of 10, 100 or 250 ml
or in sets of 7 bottles of 10 ml

See more

Test Pens PINK

22 to 60 mN/m
with accuracy: +/- 1,0 mN/m

Available:
in sets of 4, 6, and 8
or as single pens, 5 ml

See more
Test Pens PINK Jumbo

Test Pens arcotest® PINK Jumbo

30 to 50 mN/m
with accuracy: +/- 1,0 mN/m

Available:
in sets of 4, 6, and 8
or as single pens, 17 ml

See more

Test Inks arcotest® BLUE

The BLUE Test Inks are special testing liquids in ranges of defined surface tension (from 30 to 72mN/m in accordance with ISO 8296 / ASTM 2578 / DIN 53364). The surface tension of a substrate is checked by simply applying the test ink to the surface.

The BLUE Test Inks are available in a range from 18.4 to 105 mN/m.
Available in bottles or in pen form (28 to 72 mN/m).
Toxic from 24 to 57 mN/m.

observation time: 2 sec.
Test Inks BLUE

Test Inks BLUE in bottles

18,4 to 105 mN/m

with accuracy: +/- 0,5 mN/m

Available:
in bottles of 10, 100 or 250 ml
or in sets of 7 bottles of 10 ml

See more
Test Pens

Test Pens BLUE

from 28 – 60 mN/min steps of one by one
from 62 – 72 mN/m in steps of two by two

with accuracy: +/- 1,0 mN/m

Available:
in sets of 4, 6, and 8
or as single pens, 5 ml

See more

RAPIDTEST 38®

RAPIDTEST 38® Jumbo

38 mN/m approx.

RAPIDTEST 38® serves to check if the treatment of polyolefins has shown an effect.

  • extremely easy to handle
  • perfect for quick checks
  • no wiping off necessary
  • lasting display of result
  • archiving of test result possible
See more

QUICKTEST 38®

38 mN/m approx.

QUICKTEST 38® serves to check if the treatment of polyolefins has shown an effect.

  • good readability due to striking red colour
  • extremely easy to handle
  • perfect for quick checks
  • no wiping off necessary
  • lasting display of result
  • archiving of test result possible
See more

RAPIDTEST 38® Jumbo

QUICKTEST 38® Jumbo

better colour presentation
line thickness: 15 mm
contents: 15 ml
optimal for testing large film

Service

Expert advice, guarantee of the given values, reliable and prompt delivery, cooperation with our customers at home and abroad have been our absolute priority for 46 years.

Quality control

For quality assurance, the inks are tested using a state-of-the-art contact angle measuring device, taking temperature and density into account.

Safety data sheets provide information on handling, storage and transport regulations.

Purchase orders B2B

here in the online shop after registration.

Inquiries, offers Inquiries and orders in writing by post, fax, e-mail or via the contact form.
